FLEXAR
Carbon Steel Doctor Blades
High Carbon Alloyed Steel
Refined Micro structure for uniform wear
Enhanced doctoring angle and precision
Longer life and improved edge retention
Specialized heat treatment for a much higher abrasion resistance.
TOLERANCES
FLEXAR printing doctor blades (High carbon steel)
Surface
Bright Polished
Hardness
600 Hv
Flatness deviation max
0.3% of the strip width
Straightness deviation max
0.6/3000 mm
Thickness Tolerance
+ 0.01 mm
Width tolerance
+ 0.01 mm
FLEXAR Ordering Sizes
Our doctor blades of high carbon come in different slit widths and are offered in standard packages of 100-meter and 50-meter boxes.
Available Thickness - 0.10 to 0.30 mm
